Long Life Series

Voltage covers:  2V, 4V, 6V, 12V
Capacity:  From 0.5Ah to 250Ah
Designed floating service life:  @ 20°C/68°F Capacity under 18Ah is designed for 5 years, and 8 years for capacity above 24Ah.
Long Life Series batteries utilizes thick grids of modern technology are adopted so as to guarantee the design life up to 12 years. Advanced micro porous absorbed glass matt separator - minimizes diffusion of oxygen into the separator, reducing float charge current which suppressed the corrosion rate of the positive grid and extends the life of the battery.

Code	Nominal Voltage (V)	Capacity (AH)	Dimension								Weight		Terminal		PDF
			Length		Width		Height		Total Height		Kg	Lb	Type	Posi- tion
			mm	in	mm	in	mm	in	mm	in
LB6-100	6	100	194	7.64	170	6.69	207	8.15	210	8.27	16	35.28	T19	A
LB6-160	6	160	260	10.24	180	7.09	247	9.72	251	9.88	24	52.92	T19	A
LB6-180	6	180	323	12.72	178	7.01	224	8.82	228	8.98	30	66.15	T19	A
LB6-200	6	200	323	12.72	178	7.01	224	8.82	228	8.98	31	68.36	T19	A
LB12-40	12	40	197	7.76	165	6.5	170	6.69	170	6.69	14	30.87	T17	D
LB12-55	12	55	230	9.06	138	5.43	209	8.23	213	8.39	17.3	38.15	T17	C
LB12-65	12	65	350	13.78	166	6.54	176	6.93	176	6.93	21.6	47.63	T10	C
LB12-70	12	70	258	10.16	168	6.61	208	8.19	212	8.35	23.5	50.72	T18	C
LB12-80	12	80	258	10.16	168	6.61	208	8.19	212	8.35	24	52.92	T18	C
LB12-90	12	90	305	12.01	168	6.61	208	8.19	212	8.35	29	63.95	T19	C
LB12-100	12	100	330	12.99	172	6.77	215	8.46	221	8.7	31.5	69.46	T19	C
LB12-120	12	120	406	15.98	174	6.85	208	8.19	233	9.17	37	81.59	T12	C
LB12-160	12	160	530	20.87	209	8.23	214	8.43	231	9.09	50	110.3	T14	E
LB12-180	12	180	525	20.67	243	9.57	220	8.66	245	9.65	58	127.9	T14	E
LB12-200	12	200	525	20.67	243	9.57	220	8.66	245	9.65	63	138.9	T14	E
LB12-230	12	230	520	20.47	268	10.55	220	8.66	249	9.8	79	174.2	T14	E
LB12-250	12	250	520	20.47	268	10.55	220	8.66	249	9.8	85	187.4	T14	E
